General Pump YHILO130 Hi-Lo Pressure Nozzle with Variable Angle - 4050 PSI, 1/4 Inch BSP-F, 1.3 mm Orifice, Yellow
Brand:
Mfr. Model #:
YHILO130
KR Part #:
GPNYHILO130
Weight:
0.50 lbs
(0)A nozzle with a flow rate that is dependent on the supplied pressure. Plastic housing with brass, stainless steel, and Viton internal components. Handles a maximum pressure of 4050 PSI.
Prop 65
Technical Specifications
Max PSI: 4500
Inlet Port: 1/4 inch
Orifice: 1.3 millimeter
Max Temperature: 195 degrees F
Max GPM: 4
Min GPM: 1.41
Product Description
1/4" BSP-F - Plastic Nozzle
General Pump nozzle YHILO130 is great for high and low pressure applications thanks to its adjustable settings. Rated for a maximum working pressure of 4050 PSI. The nozzle's orifice measures 1.3mm. Flow rate of this nozzle varies based on the amount of water pressure, please see the specifications below for additional details. Features a 1/4" BSP-F inlet. It has an orifice measuring 1.3mm in diameter.Specifications:
- Rated PSI: 4050
- Max PSI: 4500
- Inlet: 1/4" BSP-F
- Temperature: 195° F
- Nozzle Size: #4
- Identifier: Yellow
- Orifice Diameter: 1.3 mm
- Dimensions: Ø1.49" x 4.56" Long
- Materials:
- Plastic
- Brass
- Stainless Steel
- Viton
- Gallons Per Minute (GPM)
- @500 PSI: 1.41
- @1000 PSI: 2.0
- @1500 PSI: 2.45
- @2000 PSI: 2.83
- @2500 PSI: 3.16
- @3000 PSI: 3.46
- @3500 PSI: 3.74
- @4000 PSI: 4.00
