Left Shaft Platinum Emperor Pump

The General Pump Platinum Series PEHT2012SR Emperor right shaft plunger pump is designed for rigorous, long term use at your commercial car wash. This pump features a nickel plated, forged stainless steel manifold and ceramic plungers, all designed to handle high temperatures, pressures, and chemicals with ease. This pump is for use with a maximum pressure of 3,000 PSI and can pump 4.76 gallons per minute. This General Pump Platinum Emperor pump's patented high tech packings include a dynamic low-pressure seal retainer, low-pressure seal, intermediate ring, and high-pressure seal.

Dimensions: 10.4" x 8.8" x 5.4"

Features:

• Dual lip oil seal for better oil and water sealing
• Nickel-plated crankcase and forged stainless steel manifold for optimal corrosion resistance
• Increased sliding surface of the dual diameter plunger guide provides stability, reduced friction, and reduced wear
• Optimized outlet valves
• Special seals for car wash applications up to 185 degrees F
• Plunger fastening system eliminates the risk of pressure build-up
• Large diameter sight glass
• Oversized connecting rods and large oil capacity for better cooling and lubrication
• Oversized premium tapered roller bearings
• Dust protection chamber between crankcase and manifold
• Made in Italy

Specifications:

• Max Flow: 4 GPM
• Max Pressure: 3000 PSI
• Max Inlet Pressure: 125 PSI
• RPM: 1750
• Stroke: 10mm
• Bore: 20mm
• Shaft Diameter: 24mm
• Oil Capacity: 22 oz.
• Inlet: 1/2” - 14 BSP-F
• Outlet: 3/8” - 19 BSP-F
• Horsepower: 8.2
• Max Temp: 185 degrees F
• Weight: 21 lbs
